Ramiex

Our strongest natural fibre packing

Description

Versatile, high-performance packing, cross-

plaited from top-quality bleached ramie

fibre yarns that are impregnated with an

advanced PTFE dispersion lubricant. The

result is a consistent packing of uniform

density and compressibility.

Ramie, a tropical nettle plant, produces a

fibre of extreme durability, rot resistance

and significantly greater strength than

flax, cotton or hemp.

Typical applications

Used with great success in the mining

and quarrying industries on reciprocating

pumps working at 300bar with water

containing highly abrasive particles.

Also used for water-based hydraulic

systems, pulp and paper processing

with cellulose slurry, brine circulation,

cooling water systems, and with fluids

that crystallise or contain suspended

solids.

Prime features

●

Excellent extrusion resistance.

●

Excellent abrasive resistance.

●

Excellent rot resistance.

●

Low friction and low wear.

●

Kind to shafts and sleeves.

●

Supalubrication

of yarns

(page 33)

.

Chemical properties

Compatible with media in the range

pH 4-11.

Service capabilities

Valve stem duties

Maximum temperature +120°C

Minimum temperature –30°C

Max system pressure 250bar

Centrifugal pumps & rotary

equipment

Operating temperatures

As valve stem

Maximum shaft speed 17.5m/s

Max system pressure 20bar

Reciprocating pumps & rams

Operating temperatures

As valve stem

Maximum rod speed 2m/s

Max system pressure 250bar

(

can be extended to 700bar

with special support rings

on some applications)

How supplied

Ex-stock: all popular square sections

from 3mm to 25mm, boxed in 8m

lengths. Also supplied as split preformed

rings and sets. Full fitting instructions are

included.
